1U 19" DVI Rackmount Monitor Keyboard Drawer with combo USB DVI Rackmount Monitor Keyboard touchpad
1U DVI LCD Keyboard #RKD-KVM-19-DVI KVMSwitchTech

1U 19" DVI Rackmount Monitor Keyboard Drawer with combo USB and PS2 Interface Touchpad

$1,263.00 $1,500.00 -16%

In stock — ships fast

1U 19" DVI Rackmount Monitor Keyboard is a combination of Keyboard, DVI Video and touchpad mouse (KVM) in 1U Rack drawer. This DVI Rack Mount LCD keyboard unit comes with a combo interface cable which supports both USB and PS2 keyboard interface.



  • Fast shipping
  • Genuine warranty
  • RMA support
  • Expert help

Product Features

  • 1U Rackmount Monitor drawer with 17” or 19” LCD
  • Built in Keyboard, touchpad or trackball and Samsung LCD
  • Touchpad or Trackball keyboard with combo cable for USB or PS2 and VGA 15 Pin HD / DVI video
  • Multiple keyboard language selections
  • Enhanced aesthetics with new molded front panel and two point lock
  • Adjustable mounting brackets for various rack depths
  • Slide rails with fixed positions to prevent drawer movement when typing
  • Optional Mounting hardware available for two post Telco style racks



Specifications

LCD
Samsung LCD Panel
Display Area
376(H) x 301(V) mm
Contrast Ratio
1000: 1
Viewing Angle
160 °(H) x 160 °(V) (Typ.)
Resolution
1280 x 1024
LCD MTBF
50,000 Hrs
Tr Response Time (ms)
1.3
Brightness
250 cd/m2
Panel Color
16.7M
Back Light
4 CCFTs(Cold Cathode Fluorescent tube)
Video
Horizontal Sync
64 - 80 KHz (Typ.)
Vertical Sync
60-75 Hz (Typ.)
Input Signal
RGB 0.7Vp-p / DVI-D
Power Management
VESA DPMS
Control
OSD Control
Brightness, Contrast, Colour, Clock, H.Position, V.Position, Phase, Scaling, Auto config, Input ,select, Multi window, Clear EEPROM, OSD adjust, Save
Inputs
Power
100-240VAC, 50 / 60Hz with IEC Connector
Video Input
15-pin D-Sub connector / DVI-D
Dimensions
Product (WXDXH)
17.4 x 25.6 x 1.75 inches
Packaging (WXDXH)
23.6 x 30.3 x 7.1 inches
Weight
Net
35lbs
Gross
48lbs
Certifications
CE, FCC, and RoHS
