1U 17" Rack Monitor with Integrated CAT5 KVM cat5 kvmover ip rackmound lcd keyboard

1U LCD Keyboard with IP Cat5 KVM Switch #RKD-C5-17-8IP KVMSwitchTech

1U 17" Rack Monitor with Integrated CAT5 KVM over IP Switch Touchpad, 8 Ports

Name: 1U 17" Rack Monitor with Integrated CAT5 KVM over IP Switch Touchpad, 8 Ports
Brand: KVMSwitchTech
SKU: RKD-C5-17-8IP
Price: 2217.00 USD
Availability: InStock

$2,217.00 $2,400.00 -8%

In stock — ships fast

Description :

Rackmount Monitor Keyboard with integrated CAT5 KVM over IP Switch is a combination of Keyboard, Video, touchpad Mouse (KVM) and CAT5 IP KVM Switch in 1U Rack drawer. This Rack Monitor unit with built in CAT5 KVM over IP Switch offers users the flexibility to access multiple Servers from one or multiple locations.

Fast shipping
Genuine warranty
RMA support
Expert help

Product Features

Related Dongles are at the bottom of the Page- Must be purchased separately for correct functionality
1U Rackmount LCD Keyboard with built in Cat5 KVM over IP Switch
Built in Keyboard, touchpad or trackball and Samsung LCD
Touchpad or Trackball keyboard with combo cable for USB or PS2 and VGA 15 Pin HD video
Multiple Keyboard language selections
Enhanced aesthetics with new molded front panel and two point lock
Adjustable Mounting brackets for various rack depths
Slide rails with fixed positions to prevent drawer movement when typing
Optional Mounting hardware available for two post Telco style racks
104 Key notepad Keyboard with full numerical pad
One Man installation slides for easy, quick installation
Multi lingual on screen display menu
12, 24 and 48 volt DC power options available

Rackmount LCD Keyboard with CAT5 KVM over IP Switch

Cascade KVM Switches to control up to 256 servers
Extend upto 40 meters(132ft) between servers and LCD with IP CAT5 KVM Switch
DVI-USB, VGA-USB, VGA-PS2 server interface support
Name servers up to 16 characters long
Scan Mode – Monitor servers at intervals 5 to 99 seconds
IP Access and IP Security SSL v3, RSA, CSR, https, AES, 15 user login (1 x active user)
Multi-platform support enables users to mix PCs, SUN Microsystems, IBMs, HPs, Compaq and Dell Servers

Integrated KVM Switch Options

PS2 KVM Switch, USB KVM Switch, Cat5e/Cat6 KVM Switch, IP KVM Switch and Matrix KVM Switch
Mix DVI-USB, VGA-USB, VGA-PS2 Servers
Rackmount LCD Keyboard with integrated KVM Switch offers Multi-Platform switching capability
Cost efficient Combo KVM integration
Secure remote user access (KVM Switch with TCP/IP Functionality)

Specifications

Environmental
Operating Temperature	0° to 50°C Degree
Storage Temperature	-5° to 65°C Degree
Relative Humidity	5-90%, non-condensing
Shock	10G Acceleration (11ms duration)
Vibration	5~500Hz 1G RMS Random vibration
LCD	Samsung LCD Panel
Diagonal Size	17" TFT LCD
Max. Resolution	1280 x 1024
Brightness (cd/m²)	250
Color Support	16.7 Mil
Contrast Ratio(Typ)	1000:1
Viewing Angle (H/V)	160° x 160°
Display Area (mm)	337 x 270
Tr Response Time (ms)	1.3
VGA Signal	Input Analog RGB, 0.7Vp-p
Sync. Type	Separate H/V, Composite, SOG
External Connection
Power Input	Auto sensing 100 to 240VAC, 50 / 60Hz via IEC connector
Video Input	VGA 15-pin Connector
Dimensions
Product (WXDXH)	17.4 x 25.6 x 1.75 inches
Packaging (WXDXH)	23.6 x 30.3 x 7.1 inches
Weight
Net	42lbs
Gross	54lbs
Certifications	CE, FCC, & RoHS
